At a distance of 1m from gas intake valve
**CH4 volume content≥70%
**Pressure :80~200kpa
**Pressure changing rate≤1kpa/min
**H2S≤20mg/Nm³
**Moisture content≤40mg/Nm³
Impurity particle size≤5um, Impurity content≤30mg/Nm³
If fuel gas contains higher quantity of sulfur and ammonia, it not only corrodes the pole of spark
plug seriously,but also increases the acid value, which corrodes internal parts of genset and
corrodes the genset with precipitates
Model | Engine No. | Rated power | Rated speed r/min | Size(L*W*H mm) | Net weight(KG) |
CW-20GFT | CW4105 | 20KW | 1500 | 2200×850×1300 | 900 |
CW-40GFT | CW6105 | 40KW | 1500 | 2700×850×1350 | 1200 |
CW-60GFT | CW4135 | 60KW | 1500 | 2300×850×1350 | 1300 |
CW-80GFT | CW6135 | 80KW | 1500 | 4000×120×1750 | 2300 |
CW-100GFT | CW6135 | 100KW | 1500 | 4000×120×1750 | 2300 |
CW-120GFT | CW12V135 | 120KW | 1500 | 4000×120×1750 | 4000 |
CW-200GFT | CW12V135 | 200KW | 1500 | 4000×120×1750 | 4000 |
CW-300GFT | 6190ZLDT-2 | 300KW | 1000 | 5600×1970×2170 | 9000 |
CW-400GFT | 12V190DT-2 | 400KW | 1000 | 5600×1970×2235 | 11000 |
CW-500GFT | 12V190ZLDT-2 | 500KW | 1000 | 5600×1970×2670 | 11500 |
CW-600GFT | 12V190ZLT | 600KW | 1000 | 5600×1970×2670 | 11500 |
190 Series Natual Gas Generator Main Specification | |||||
Model | CW-20GFT | CW-40GFT | CW-80GFT | CW-150GFT | CW-200GFT |
Engine No. | CW4105 | CW6105 | CW6135 | CW12V135 | CW12V135 |
Gas max type | outside | outside | Outside | Outside | outside |
Rated power | 20kw | 40kw | 80kw | 150kw | 200kw |
Rated voltage | 400V/230V | 400V/230V | 400V/230V | 400V/230V | 400V/230V |
phase | 3p4w | 3p4w | 3p4w | 3p4w | 3p4w |
Rated frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz |
Rated speed | 1500r/min | 1500r/min | 1500r/min | 1500r/min | 1000r/min |
Rated power factor | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
Rate current | 36A | 72A | 144A | 270A | 360A |
Heat consumption | ≤11.5mj/kw.h | ≤11.5mj/kw.h | ≤11.5mj/kw.h | ≤11.5mj/kw.h | ≤11.5mj/kw.h |
Press | 3-20kpa | 3-20kpa | 3-20kpa | 3-20kpa | 3-20kpa |
Cylinder No. | 4 | 6 | 6 | 12 V | 12 |
Cylinder diameter | 105mm | 105mm | 135mm | 135mm | 135mm |
stroke | 125mm | 125mm | 150mm | 150mm | 150mm |
Compression ratio | 11:01 | 11:01 | 10:01 | 10:01 | 10:01 |
Intake mode | Nature intake | Nature intake | Nature intake | Nature intake | Nature intake |
Sparking mode | Sparking plug | Sparking plug | Sparking plug | Sparking plug | Sparking plug |
Voltage regulation mode | automatic | automatic | automatic | automatic | automatic |
Speed regulate mode | Electronic speed regulate | Electronic speed regulate | Electronic speed regulate | Electronic speed regulate | electronic speed regulate |
Lubricating mode | Press and plash | Press and plash | Press and plash | Press and plash | Press and plash |
Cooling mode | Circulating water cooled | Circulating water cooled | Circulating water cooled | Circulating water cooled | Circulating water cooled |
Starting mode | 24V electric motor | 24V electric motor | 24V electric motor | 24V electric motor | 24V |
Overhaul time | ≥2500 | ≥2500 | ≥2500 | ≥2500 | ≥2500 |
Noise | ≤105 | ≤105 | ≤105 | ≤105 | ≤105 |
Exhaust temperature | no more than 650ºC | ** | ** | ** | ** |
Displacement | 2.8L | 5.2L | 10.4L | 20L | 25.4L |
Size | 2200×850×1300 | 2300×850×1350 | 4000×1200×1750 | 4000×1200×1750 | 6000×1900×2170 |
Weight | 900kg | 1200kg | 2300kg | 4000kg | 4000kg |
Shandong Chargewe Power Co.,Ltd is a comprehensive high-tech enterprises,focusing on new type of
environmental protection generators' development,production and sale . We have our own brand
"CHARGEWE" generator set, including diesel generator, gas generator,biogas generator, nature
gas generator etc. from 20kw -1000kw.
4. Quality Control :
Every product must be through a strictly test before delivery.The items been tested on the
generating sets are mainly as follows: 1.Each genset is tested more than 4 hours totally.They
aretested on idle load,load,Fully load and 10% overload. 2.The noise level is tested. 3.Operation
ofthe various meters on the control panel is tested. 4.The generating set's appearance and all
marks are checked as well.
Wooden cases and cartons or Bulk
1.How to choose the right model?
A: It depends on real output power, Voltage, Frequency and gas type.
2.What is the oil consumption and capacity per hour?
A: 1.0-1.63g of lubricant oil consumption per hour. 1.0 Cubic meter gas can produce 1.5-3.0kw/h
power. The capacity depends on gas energy. E.g 1.0 Cubic meter natural gas produce about 3.0kw/h
3.What is the overhaul?
A: About 30000 working hours. A week is enough to finish.
4. What is the warranty?
A: 1 year. Inside this 1 year, we offer all spare parts free of charge. After this period, spare
parts are not free. But, a set of spare parts will be shipped together with machine free.
5. How is the service?
A: We offer installation,repair and maintain service abroad. And online guide service if needed
anytime. Our before-sale, in-sale and after-sale service are all trustable, you can name it.
